When your industrial Ethernet devices need reliable DC power in harsh conditions, a compact, rugged power supply is essential - otherwise downtime can cost you dearly. The PLANET (PWR-480-48), 480 W, 100-240 V, 50 - 60 Hz, 4.8 A, DIN Rail Power Supply delivers steady 48 V output from any standard AC source, fitting neatly onto a DIN rail for quick, secure installation.
Usages of a 480 W Power Supply
Designed for factory floors, automation panels and outdoor control cabinets, this unit powers Ethernet switches, sensors and PLCs where space is limited and environmental stress is high. Its universal 100-240 V input lets you connect it to any mains supply, keeping your equipment running smoothly day after day.
Benefits of PLANET Power Supply
- Robust protection: Over-voltage, overload, short-circuit and overheating safeguards keep your system safe.
- Wide temperature range: Operates from -20 °C to 70 °C, so it endures cold warehouses and hot enclosures.
- Passive cooling: No fans mean silent operation and lower maintenance.
- Compact dimensions: 128 mm × 125 mm × 85 mm fits tight DIN-rail spaces.
- Easy mounting: Fits standard TS-35 rails without extra hardware.
Why Choose PLANET Power Supply
Choosing this PLANET power supply means you get industrial-grade reliability without the bulk of a larger unit. Its active power factor correction ensures efficient energy use, reducing your electricity costs while delivering the full 480 W you need. The dual-colour (blue, grey) housing not only looks professional but also resists corrosion in demanding environments.
In addition, the unit complies with UL508 and TUV EN60950-1 safety standards, giving you peace of mind that it meets rigorous international requirements. Whether you are retrofitting an existing panel or building a new control system, the PLANET power supply offers a plug-and-play solution that minimises wiring errors and installation time.
Key Features of a 480 W Power Supply
- Power output: 480 W. Provides ample power for multiple devices on a single line.
- Input voltage: 100-240 V AC. Works with any global mains supply.
- Input frequency: 50-60 Hz. Compatible with standard power grids worldwide.
- Input current: 4.8 A. Low current draw keeps wiring simple.
- Power factor correction: Active. Improves efficiency and reduces waste.
- Cooling type: Passive. No moving parts, so it stays quiet and reliable.
- Operating temperature: -20 °C to 70 °C. Handles extreme indoor and outdoor conditions.
- Weight: 1.5 kg. Light enough for easy handling yet solidly built.
- Dimensions: Height 128 mm, Depth 125 mm, Width 85 mm. Fits comfortably on DIN rails.
- Safety standards: UL508, TUV EN60950-1. Certified for industrial safety compliance.
Specifications
| Power |
| Power protection features |
Over voltage, Overheating, Overload, Short circuit |
| Power Factor Correction (PFC) type |
Active |
| Input current |
4.8 A |
| AC input frequency |
50 - 60 Hz |
| AC input voltage |
100-240 V |
| Total power |
480 W |
| Design |
| On/off switch |
No |
| Cooling type |
Passive |
| Product colour |
Blue, Grey |
| Operational conditions |
| Operating temperature (T-T) |
-20 - 70 °C |
| Storage relative humidity (H-H) |
10 - 95% |
| Operating relative humidity (H-H) |
20 - 95% |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating temperature (T-T) |
-20 - 70 °C |
| Safety regulation & standards |
| Safety |
Ul508, TUV EN60950-1 |
| Weight & dimensions |
| Weight |
1.5 kg |
| Height |
128 mm |
| Depth |
125 mm |
| Width |
85 mm |
| Other features |
| Output power description |
480W |
